1.2L REVOTRON ENGINE
98
PRE-SILENCER REMOVAL
1. Remove the Pre-silencer mounting Nuts from
main silencer side.
2. Remove the one rubber hanger from front end
of pre silencer and other one is from rear end.
3. Remove Front Floor Tube.
4. Remove silencer mountings with Catcon Assy.
5. Take out the Pre silencer assembly.
FITMENT
For fitment follow reverse procedure of removal.
FRONT PIPE WITH CLOSED CATALYTIC
CONVERTER
REMOVAL
1. Remove all connections including lambda
sensor.
2. Remove Front silencer pipe.
3. Remove 4 mounting nuts on the catcon Assy.
4. Remove CCC mounting bracket bolts from both
sides.
5. Remove the CCC.
FITMENT
For fitment follow the reverse procedure of
removal.
NOTE
Use new gaskets every time while fitment
and tighten nuts and bolts to specified
torque.
