1.2L REVOTRON ENGINE
90
B. ENGINE REMOVAL AND REFITMENT FOR
AMT VEHICLE:
Description
In many cases, the engine can be repaired while
still in the vehicle. The engine must be removed in
cases where the engine has been severely
damaged beyond repair or the type of repair
necessitates removal. Use the following procedure
as a guide to engine removal and installation.
Engine Removal
NOTE
Access to an overhead hoist will ease
removal of the engine.
Use a vehicle lifting hoist, if available.
1. Place the vehicle on the two post lift and
engage the parking brake.
2. Open the hood (bonnet) of the vehicle.
3. Remove the air filter assembly and intake
system hoses from the engine.
4. Disconnect the negative (-) cable and then the
positive (+) cable from the engine.
5. Remove Battery
6. Remove Battery Tray.
7. Disconnect and label the Engine wiring
harness connection with ECU.
8. Remove ECU from the vehicle.
9. Raise the vehicle off the ground and drain the
engine oil by removing the drain plug into a
suitable container.
