DTC Troubleshooting Data
Version: 1.0
Date: 16-Oct-2018
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
Author: ERC
Page: 192 of 202
After rectification, ensure the following points using TML diagnostic tool before handing over to customer
.
a)
Check whether BCM ECU is communicating with diagnostic Tool or not.
b)
DTC should not be in ECU fault memory.
Circuit Schematic Diagram:- N.A.
Component Location & Image: - N.A
Connector Location: N.A
BCM connector ECU side layout
BCM Connector A ECU side pin out
Connector View & Information: -
