DTC’s confirmation:-

After rectification, Rotate temperature Knob and ensure the following points by referring Temperature parameters using

TML diagnostic tool before handing over to customer.

a) Physical check of temperature variation when requested.

b) Read ECU parameter

, Air Temperature Drive Motor A Output

Circuit Schematic Diagram:-

“Refer the circuit schematics from the tool”

Component Location & Image:-

Connector Location: -

HVAC kit

Connector View & Information: -

Connector end view - showing the cable entry pin-out
