B1F3E-71:- Temperature Door Control Motor - Actuator stuck;
:
ISO Code
B1F3E-71
Customer Symptom
No air temperature control (manual or automatic)
Fault Effects (On Vehicle)
The motor is blocked and its motion toward either end is not
possible
Lamp Status (If Any)
NA
Fault Detection Condition
Temperature Door Control Motor – Actuator Stuck
Normal Operating Condition
Air Temperature Drive Motor is moving according to the input
Probable Trouble Area
Motor is stuck because of a mechanical block or obstruction
in movement of flap
Healing Condition
NA
Component Details:
The actuator controls the position of the temperature blend door based on the voltage signal from the FATC module.
Potentiometer, inside the actuator, sends a feedback signal to the controller and controller cuts off the voltage signal
coming from the controller when the required door position is achieved.
Preliminary Checks:
Switch On the IGN & perform the following check.
1) Connect the Diagnostics tool & check the DTC fault code
2) If the fault code exists, refer the Trouble Shooting.
