B1F2B-11:- Air Conditioning Compressor Request – circuit short to Ground;
Overview:
ISO Code
B1F2B-11
Customer Symptom
No cooling
Fault Effects (On Vehicle)
AC will remain Off. Cooling cannot be achieved.
Lamp Status (If Any)
NA
Fault Detection Condition
Compressor permanently off
Normal Operating Condition
Air conditioner is functional and voltage at pin no 27 of green
connector should be 12V
Probable Trouble Area
AC request drive line is short circuited to ground
Healing Condition
NA
Component Details:
Compressor - The compressor is the heart of an auto's air conditioning system, circulating the refrigerant that is vital to
proper operation of AC.
Preliminary Checks:
Switch On the IGN & Engine, perform the following check.
1) Connect the Diagnostics tool & check the DTC fault code
2) Read ECU Parameter,
Air Conditioning Compressor Request Output
.
