Start
B1644-05
Is this Historic DTC?
Clear the DTC, make the IGN OFF,
wait for 20 seconds and turn ON
the IGN
Stop
YES
Check the pairing process
whether followed correctly or not
Is process followed
correctly?
Check the DTC of Centre Console
Antenna is logged or not
NO
Stop
YES
Stop
NO
Follow the correct process and try
to pair all the UIDs again
Is DTC still present?
NO
Is Antenna DTC logged?
Rectify antenna DTC issue and try
to pair all required UIDs again
Is DTC still present?
Stop
NO
YES
YES
Replace not working UID (follow
the replacement procedure) and
try to pair all UIDs again.
NO
YES
Is DTC still present?
Stop
NO
Replace the ECU(follow the
replacement procedure) and pair
all required UIDs again.
