3414 / 4910
Vehicle Platform: OSPREY / AMP
ECU Name: PEPS
DTC Troubleshooting Data
Version: 1.2
Date: 29 Mar 2017
Author:
Rajasekhara Reddy
Page: 132 of 369
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
Connector View & Information:-
NA
Inspection Method:-
1. Keep the UID anywhere inside the vehicle, passive start shall be possible
2. Keep the UID outside the vehicle, passive start shall not be possible
3. Make IGN OFF, keep the UID on driver side within wake-up range i.e. 1-2 meter, passive entry via driver door shall
be possible
4. Make IGN OFF; keep the UID on driver side outside wake-up range i.e. beyond 2 meter, passive entry via driver
door shall not be possible.
