U3006 - 17:-Control Module Input Power "A" - circuit voltage above threshold

Overview:-

ISO Code

U3006-17

Customer Symptom

PEPS will probably not function or will function intermittently or

partially

Fault Effects (On Vehicle)

Cannot determine scope without knowledge of power line

applicability

Lamp Status (If Any)

None

Fault Detection Condition

If Battery(supply) voltage greater than 16V Alternator voltage

o/p is greater than 14.5V.

Normal Operating Condition

Normal operating range:-

ECU will be awake from 6V to 16 V.

Full assistance is b/w 11.5 to 16 volts.

Reduced assistance is b/w 9 to 11.5 V

Probable Trouble Area

Vehicle electrical fault

Healing Condition

N/A

Table 2:- U3006-17 overview details

Component Details:-

N/A

Preliminary Checks:-

1. Voltage at the battery terminals should be greater than 11.5V.

2. PEPS power supply connector should have greater than 11.5V for full assistance.

3. Check battery cable and PEPS connector terminals for damage.

4. Check PEPS ECU for pin bend/damage.

5. Alternator output voltage should be between 13.5 V to 14.5 V in engine running condition.
