Trouble Shooting:-
DTC’s confirmation:-
After rectification, ensure the following points before handing over the system to the customer
1. Battery Voltage is between 9 to 16V.
2. Replacement of ECU.
3. Drive the vehicle on road and check the assistance.
Circuit Schematic Diagram:-
N/A
Component Location & Image:-
N/A
Reset the ECU
(Remove the
power plug from ECU and
reconnect after about 5 minutes
)
Yes
No
Is
DTC still
present?
Stop
Replace
the ECU.
Yes
Is DTC
Present?
No
Stop
1. Connect the TML Diagnostic Tool
.
.
2
Turn the Ignition ON
)
. Check the status of DTC’s (Memorized/Current
3
4. Record the DTC & Clear
. Turn Ignition OFF & ON
5
6. Verify If
U1006 – 42
is present
