Vehicle Platform: OSPREY / AMP
ECU Name: PEPS
DTC Troubleshooting Data
Version: 1.2
Date: 29 Mar 2017
Author:
Rajasekhara Reddy
Page: 11 of 369
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
DTC’s confirmation:-
After rectification, ensure the following points before handing over the system to the customer
a) Battery Voltage is between 9 to 16V.
b) Replacement of ECU
c) Drive the vehicle on road and check the assistance
Circuit Schematic Diagram:-
N/A
Component Location & Image:-
N/A
Connector Location:-
N/A
Connector View & Information:-
Connector Number
Pin
number
Signal Name
Signal Description
Signal type
(Select from
drop down)
3
10
PEPS_ECU_Supply
ECU Battery Power Supply 1
Power
3
9
PEPS_ECU_Supply
ECU Battery Power Supply 1
Power
Inspection Method:-
N/A
