U1006 - 42:-Control Module Internal- general memory failure
Overview:-
ISO Code
U1006-42
Customer Symptom
PEPS will probably not function or will function intermittently or
partially
Fault Effects (On Vehicle)
HU unit inoperative
Lamp Status (If Any)
None
Fault Detection Condition
Fault logged in the event of an error in the data flash memory
Normal Operating Condition
Normal operating range:-
ECU will be awake from 6V to 16 V.
Full assistance is b/w 11.5 to 16 volts.
Reduced assistance is b/w 9 to 11.5 V
Probable Trouble Area
PEPS internal damage
Healing Condition
N/A
Table 3:- U1006-42 overview details
Component Details:-
N/A
Preliminary Checks:-
1. Voltage at the battery terminals should be greater than 11.5V.
2. PEPS power supply connector should have greater than 11.5V for full assistance.
3. Check battery cable and PEPS connector terminals for damage.
4. Check PEPS ECU for pin bend/damage.
5. Alternator output voltage should be between 13.5 V to 14.5 V in engine running condition.
