Vehicle Platform: OSPREY
ECU Name: Hella Body Control Module (BCM) DTC
Troubleshooting Data
Version: 1.4
Date: 15 May 2018
Author: Body CoC
Page: 645 of 855
Copyright ©
TATA MOTORS Ltd.
This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.
A
Is connector
faulty?
Check continuity between BCM connector
pin[C2-11] and BCM ground pin[C1-34/C1-47].
Continuity
found?
1. Remove Rear left turn indicator LED matting connector.
2. Perform visual check of connector for pins bend or damaged etc.
Is connector
faulty?
LED faulty?
BCM ECU faulty
Replace BCM ECU
1. Replace rear left turn
indicator LED.
Correct connector
fault(Terminals bend)
Correct BCM side wiring
harness.(Short to ground)
Correct connector
fault(Terminals bend)
B
YES
YES
YES
YES
NO
NO
NO
NO
B2269– 11 : Rear Left Turn Indicator LEDs – circuit short to ground
Check the LED is faulty
