8) Remove BCM connector. Take out right DRL output wire (c4-39) from connector. Reconnect all

connections including battery. Check if DRL is coming ON. If yes, reconnect all connectors firmly.

9) If fault is not found, then replace ECU.

Circuit Schematic Diagram:-

Note:

For detailed information please refer latest BCM wiring harness schematic.

Connector View & Information: -

Please refer respective BCM Drawing for BCM connector PIN details

Inspection Method: -
