6) Remove left DRL and check continuity between BCM pin (c4-52) and BCM battery (c3-2 / c3-1). If
continuity found, correct BCM side wiring harness.
7) If fault is not found, then replace ECU.
Circuit Schematic Diagram:-
Note:
For detailed information please refer latest BCM wiring harness schematic.
Connector View & Information: -
Please refer respective BCM Drawing for BCM connector PIN details
Inspection Method: -
NA
