U0164-08:- Lost communication with HVAC Control Module- Message Timeout Failure

Overview:

ISO Code

U0164-08

Customer Symptom

Heater rear window does not operate

Fault Effects (On Vehicle)

Heater rear window does not operate

Lamp Status (If Any)

N.A

Fault Detection Condition

1. HVAC connector is not connected properly or

disconnected from its location

2. CAN Stub wire from HVAC connector side is

disconnected.

3. HVAC ECU is not powered up

Normal Operating Condition

HVAC ECU communicates properly with TML diagnostic

Tool

Probable Trouble Area

Disconnection of the HVAC connector

Healing Condition

To fix the HVAC connector correctly and Fix the wiring

harness issues from HVAC side.
