TCM ECU Pin assignment
Vehicle Connector-1
Pin No.
Pin Name
Description
45
CAN_H
CAN High
33
CAN_L
CAN Low
28
Ign
Ignition
27
Vbat
Supply Voltage Battery
1,2
GND
Battery GND
