ECU Pin assignment (Applicable for petrol ECM)
Vehicle Connector-1
Pin No.
Pin Name
Description
132
CAN_H
CAN High
144
CAN_L
CAN Low
116
Ign
Ignition
155,156 Vbat
Supply Voltage Battery
153,154 GND
Battery GND
ECU Pin assignment (Applicable for Diesel ECM)
Vehicle Connector-1
Pin No.
Pin Name
Description
64
CAN_H
CAN High
40
CAN_L
CAN Low
23
Ign
Ignition
4,5,6
Vbat
Supply Voltage Battery
1,2,3
GND
Battery GND
