Trouble Shooting:-
Start
Read IVN DTCs in BCM
If MTO logged against
TCM in current state?
No (In history)
Check continuity between TCM CAN_H (52
pin connector pin no.45 ) to IPC CAN_H(pin
no.6 ) and TCM CAN_L (52 pin connector
pin no.33 ) to IPC CAN_L(pin no. 5) in
vehicle wiring side connector.
Is continuity
there?
Repair the wiring
harness
Clear DTC
Stop
Check Ignition (52 pin connector pin no.28),
Battery (52 pin connector pin no.27) and
Ground (52 pin connector pin no.1,2 ) of TCM
is properly connected or not. Also check fuse
blown (Battery fuse 15A and ignition fuse 10A)
Do necessary repair in the harness
Yes
Yes
No
U0101-08 Loss of communication with TCM
