TRANSAXLE TA6300
46
7. Place the 2nd Gear on ring.
8. Place sub-assembly 3
rd
& 4
th
gear on lay
shaft.
9. Place sub-assembly 5
th
& 6
th
gear on lay
shaft.
10. Press deep groove ball bearing on lay shaft
by using drift part no 2870 5890 3256.
11. Tighten the locking screw of lay shaft.
12. Press cylindrical roller bearing outer race on
housing front half-using drift part no 2870
5890 3256.
