TRANSAXLE TA6300
49
7. Check the free play of differential gears. It
should be 0-0.1 mm.
Note:
If the value of play is not within
specifications, then try with different thickness
washer.
8. Assemble Dowel sleeve heavy 6x40.
To check backlash, hold the two different
pinions and one side gear and check free play
or remaining side gear teeth flank as shown in
9. Fix sensing wheel with recess inside using
drift part no. 2654 5890 3507.
10. Press taper roller bearings outer race
bearing on front housing using drift part no.
2751 5890 2627.
11. Press taper roller bearings inner on front
housing using drift part no. 2751 5890 2622.
12. Press taper roller bearings inner on
differential using drift part no. 2751 5890
2622.
13. Press taper roller bearings outer race
bearing on differential using drift part no.
2751 5890 2627.
