7. Install washer thrust onto the output shaft.

8. Couple strainer with case and insert the magnet

into the transfer case slot.

D. CHAIN DRIVE

1. Holding each sprocket with drive chain tight and

parallel with transfer case, install the drive chain

assembly with sprockets to the output shafts.

NOTE



The chain lock should face towards the upward

direction.



The groove provided on the sprocket of the

lower output shaft should be in upward

direction.

2. Rotate the driven sprocket slightly to engage

splines on the front output shaft.
