OIL COOLER
59
TRANSMISSION AIR OILCOOLER REMOVAL
PROCEDURE WITHOUT HOSES AND TUBES:
1. Remove the stone guard intercooler
2. Open the bonnet and remove the upper sealing
duct and upper sealing duct.
3. Loosen and remove three mounting screws
along with the washers from the top side of the
bumper.
4. Loosen three mounting three screws from the
bottom of the bumper.
5. Remove the Mud flap.
6. Remove the fasteners of panel wheel arch
inner.
