TRANSMISSION
19
Fluid Drain & Oil Pan Removing Procedure
1. Place Vehicle on Hoist.
• Transmission Selector in Park Position –P
• Ignition “OFF”
2. Lift vehicle to access Transmission.
3. Remove the main transmission protection.
NOTE:
The automatic transmission fluid may flow out the
oil pan. Put a container under transmission drain
hole.
4. Place a suitable drain pan under the
transmission.
5. Wait for transmission fluid to reach ambient
temperature.
6. Loose the Oil Pan Overfill Plug.
7. Inspect the O-ring seal and plug. If used,
discard the plug.
8. If the fluid is flowing as a steady stream, wait
until the fluid begins to drip.
9. Loosen the 17 Oil Pan bolts by using a
hexagonal M10 wrench.
10. Remove the Oil Pan and the gasket.
Important:
Inspect fluid pan sealing surface.
The gasket is a controlled compression over
molded reusable gasket.
Oil pan filled with 6Ltr oil.
