1902 / 1906
HVAC
88
CONNECTOR DETAILS
PINOUT DETAILS
PIN NO
DESCRIPTION
1
Analog Gnd
2
Incar sensor supply (
Vcc
)
3
Incar aspirator (-)
4
Incar aspirator (+)
REMOVAL
1. Remove the steering column upper Cover.
2. Remove the instrument cluster cover.
3. Disconnect the electrical connection of Incar sen-
sor.
4. Remove two mounting screws of Incar sensor.
5. Take out the sensor.
