BODY
64
S. FRONT FENDER
REMOVAL
1. Remove front bumper assembly.
(For
procedure refer bumper removal process)
2. Remove front wheel arch cover.
(For
procedure refer front wheel arch removal
process)
3. Loosen and remove mounting screws
(4 Nos.)
along with the washers.
4. Open the front door. Loosen and remove the
mounting screw along with the washer from
the top.
5. Remove the valance cover.
(For procedure
refer valance cover removal process.)
FITMENT
For fitment follow reverse procedure of removal.
T. FRONT WHEEL ARCH COVER
REMOVAL
1. Loosen and remove outer wheel arch
mounting screws
(4Nos.)
.
2. Loosen and remove the mounting screw which
connects the arch cover to the front bumper.
3. Remove the front mud flap by removing 3nos
screws and 02 nos plastic rivets.
