1800 / 1906
BODY
65
4. Carefully pull out the front wheel arch cover
and separate it from the vehicle.
FITMENT
For fitment follow reverse procedure of removal.
NOTE
Properly locate the front wheel arch cover on the
fender.
U. VALANCE COVER
REMOVAL
1. Remove front wheel arch cover.
(For
procedure refer front wheel arch cover removal
process)
2. Loosen and remove the cross flanged screw at
the front.
3. Loosen and remove mounting nuts
(7 Nos.)
from the inner side of the cab.
4. Pull out the valance cover carefully and
separate it from the vehicle.
FITMENT
For fitment follow reverse procedure of removal.
NOTE
Before assembly check the condition of plastic
clips if found damaged replace with new one at
the time of assembly.
V. REAR DOOR WHEEL CLADDING
REMOVAL
1. Open the rear door.
2. Loosen and remove 02nos (M6) mounting
screws of rear door cladding cover.
