HEXA

BODY

K. TRIMS:

I. “A” PILLAR TRIM:

REMOVAL:

1. Remove the cap and then remove the

mounting screw.

2. Pull out the trim outwards and separate it from

the vehicle.

ASSEMBLY:

For assembly follow the reverse procedure of

removal.

NOTE:

Before assembly check the trim clip and if found

damage replace with new one.

II.

“B” PILLAR TRIM:

REMOVAL:

1. Pull out the “B” pillar lower trim.

2. Loosen and remove the mounting screw of the

upper trim and pull out the upper trim from the

“B” pillar.

3. Remove the seat belt lower mounting.

4. Remove “B” pillar air vent.

5. Remove the bottom mounting screw of “B”

pillar upper trim and take out the trim.
