FRONT AXLE (4X4)
34
6. Lock the wheel bolts on the spindle suitably
without damaging the threads and remove the
bolts connecting brake disc and spindle.
7. Tap the brake disc with nylon mallet and
separate the spindle and brake disc.
8. Strike with the mallet and remove the wheel
bolts from spindle.
9. Take the Knuckle sub assembly and remove
the circlip with the help of circlip plier.
10.Mount the knuckle on the press machine and
remove the bearing from knuckle using bearing
pressing dolly.
(Part No.287058903313)
NOTE
Ensure that bearing is not damaged while
removing from the knuckle.
Ensure Circlip is removed prior to remove the
bearing as bearing comes out from circlip side
of knuckle.
