FRONT AXLE (4X4)
28
13.Assemble dummy differential bearings
(Part
No. 270458903309)
in to the differential case
using dolly
(Part No. 270458903325).
14.Assemble differential case into carrier.
(Without Ring Gear.)
15.Mount dial indicator with a magnetic base.
Locate its tip on that surface of case and force
differential assembly to the extreme in the
direction towards the indicator.
16.With force still applied, set indicator to zero.
Force differential assembly to the extreme end
in opposite direction.
17.Repeat above steps until the same reading is
obtained.
18.Record reading in the format given as 'A'.
19.Remove dummy bearings
(Part No. 2704 5890
33 09)
and set aside.
20.Assemble ring gear to case. Torque ring gear
screws to specification.
NOTE
Use new ring gear screws at the time of
assembly.
21.Again assemble master differential bearings
(Part No. 2704 589 033 09)
on to differential
case.
