ELECTRICAL
66
8.4.8 REGISTRATION PLATE LAMP
It consists of LED type lamp fitted on Tailgate
Garnish
REMOVAL:
1. Pry out the lamp assembly from the cutout
provided on the tailgate garnish.
2. Disconnect the electrical connection.
3. Take out the lamp.
REFITMENT:
1. Connect the electrical connection.
2. Fit the lamp into the cutout provided on the
tailgate garnish.(
Snap fitted
)
8.4.9 HIGH MOUNTED STOP LAMP
This lamp is LED type. It is mounted on the inner
panel of the tailgate.
REMOVAL:
1. Open the tailgate.
2. Remove the upper tailgate trim.
3. Remove two mounting screws of the high
mounted stop lamp.
4. Disconnect the electrical connection.
5. Take out the lamp.
