SAFARI STORME MY14

TRANSFER CASE

TANSFER CASE

NOTE

If required remove the two shift fork facing from the

shift fork assembly.

G. FRONT OUTPUT SHAFT AND YOKE

1. Holding the end yoke with the yoke holder

(Part no. 2870 5890 2601)

remove the nut

(1)

and washer

(2)

2. Pull out the front yoke assembly

(3)

with the

standard tool.

3. Remove the lower out put shaft

4. Press out deflector from the yoke only if

replacement is required. Using dust deflector

press tool

(Part no. 2870 5890 26 07)
