SAFARI

GEAR BOX G-76

Take out shifter shaft 3rd/4th (118) along with inter

lock pin (146)

Fig. 25

Take out main shaft assembly along with the counter

shaft and shifter shafts from the gear box housing -

Rear half.

Fig. 26

Note :

Ensure that engaging sleeve does not

jump out of engaging gear.

Take out inter lock balls (138a)

Fig. 27

Separate out counter shaft assembly and shifter

shafts from main shaft assembly.

Fig.27

Fig. 26

Fig. 25

Inter lock

balls

138

138a
