SAFARI

GEAR BOX G-76

Take out 1st speed gear assy. (35) along with 1st/

2nd shifter sleeve (33) and engaging gear (32).

Fig.

Remove needle roller cage (36)

Separate out synchro cones (17a)

Gently separate out shifter sleeve from engaging gear

and remove springs (19a) carriers (20a) and balls

(21a).

Hold the main shaft assembly upside down.

Pull out taper roller bearing inner race (11a) with help

of puller 2654 5890 26 12.

Fig. 37

Pull out spacer and 5th assembly (41).

Fig. 38

Remove needle roller cage (39).

Separate out spacer (40).

Remove snap ring (31a).

Fig. 39

Fig. 38

Fig. 37

Fig. 36
