SAFARI

GEAR BOX G-76

Remove spring clip (170) and push out cylindrical

pin (171).

Fig. 5

Pull out shifting yoke (169) from selector & shifter

shaft.

Pry out oil seal (116) from selector and shifter shaft.

Remove spacer (115)

Hold the coupling flange (44) with the holder,

2651 5890 35 11. ( for Tata Motors make)

Un-stake and remove main shaft nut (45). Pull out

coupling flange.

Fig. 6

Unscrew nuts (65) and take out Assy. gear case cover

- Rear (68). Take out main shaft and counter shaft

play adjusting shims (10a & 70) from cover and keep

them properly.

Fig. 7

Take out speedo drive gear (42) from main shaft (46)

Fig. 8

Fig. 7

Fig. 6

Fig.5
