486 PL ENGINE
P
Remove the ribbed flexible hose fitted before throttle
assembly. Fig. 66
Fig. 68
Fig. 67
Fig. 66
Connection pipe
Connection
pipe
Oil Vapour
Return Hose
Remove the by pass hose (by passing throttle valve).
Fig. 67
Remove connection pipe & oil vapour (blow by)
return hose.
Remove rubber connector. Fig. 68
