SAFARI

486 PL ENGINE

Remove crankshaft gear with puller Pt. No. 2654

5890 0305. Fig. 50

Fig. 52

Fig. 51

Fig. 50

Remove

Timing belt tensioner roller.

Idler roller & timing gear train rear cover (right).

Fig. 51

Remove the bolts of timing gear train rear cover

(back plate) (left) and remove water pump. Fig. 52

(Turn the engine upside down on the stand)

WATER PUMP
