486 PL ENGINE
P
Piston & Connecting Rods :
Remove piston pin spring clips, with suitable plier.
Fig. 82
Fig. 84
Fig. 83
Fig. 82
Remove piston pin from the piston by pushing them
out using soft drift. Fig. 83
Remove connecting rod.
Remove piston rings using ring expander Fig. 84
Remove bushes of connecting rod using a suitable
drift. (If necessary).
