SAFARI

486 PL ENGINE

Remove exhaust gas recirculation (EGR) pipe from

exhaust manifold to inlet manifold. Fig. 39

Remove exhaust manifold. Fig. 40

Remove the cam shaft phase sensor. Fig. 41

Remove the connector pin support bracket from

intake manifold.

Unscrew the bolts from inlet manifold to the support

bracket, which is below the intake manifold on

crankcase. Fig. 42

Fig. 42

Fig. 41

Fig. 40

Fig. 39
