GEAR BOX G-76
Apply adhesive gasket eliminator over front cover face
and fit it over housing front.
Place measured shims of drive shaft and counter shaft
at the seat of front cover.
Put hex nuts along with bright washer and spring
washer and tighten them. Ref Fig. 121
Fit the bearing tube and tighten the bolts. Ref Fig. 122
Check free movement of roller of detent. Carefully fit
detent in a bore of housing - front, keeping roller
horizontally and ensure that it is located properly over
selector shaft notch.
Fit detent spring and then press plug.
Slide speedo drive gear over main shaft. Ref Fig 123
Fig. 121
Fig. 122
Fig. 123
