SUPPLEMENTARY RESTRAINT SYSTEM (SRS)

11

PINOUT: CONNECTOR - A

SRS

ECU

Pin

PIN DESCRIPTION

1

Can High

2

Can Low

3

Low side Driver

4

Not Applicable

5

Crash Output

6

Not Applicable

7

Common Switch GND

8

Rear Middle Buckle Switch

9

Not Used

10

Not Used

11

Not Applicable

12

Supply voltage Battery

13

Rear Buckle Switch Driver Side

14

Rear Buckle Switch Passenger Side

15

Front Airbag Driver, Minus

16

Front Airbag Driver, Plus

17

Front Airbag Passenger, Plus

18

Front Airbag Passenger, Minus

19

Belt Tensioner Front Driver, Minus

20

Belt Tensioner Front Driver, Plus

21

Belt Tensioner Front Passenger, Plus

22

Belt Tensioner Front Passenger, Minus

23

Power GND

24

Not Used

CONNECTOR - B

SRS

ECU

Pin

PIN DESCRIPTION

1

Not Used

2

Not Used

3

Not Used

4

Not Used

5

Driver Front Impact Sensor, Plus

6

Driver Front Impact Sensor, Minus

7

Passenger Front Impact Sensor, Minus

8

Passenger Front Impact Sensor, Plus

9

Not Used

10

Not Used

11

Not Used

12

Not Used

13

Not Used

14

Not Used

15

Not Used

16

Not Used

17

Not Used

18

Not Used

19

Not Used

20

Not Used

21

Not Used

22

Not Used

23

Not Used

24

Not Used
