SUPPLEMENTARY RESTRAINT SYSTEM (SRS)
16
ON VEHICLE SERVICE
REMOVAL
1. Disconnect the battery connections.
2. Remove Glow box. (For procedure refer glow
box removal process in Body Section)
3. Disconnect the electrical connector from the
PAB module.
4. Loosen and remove the mounting bolts which
hold the air bag bracket with the cross car
beam.
5. Carefully remove the PAB unit from the
Dashboard by removing all snaps and clips.
FITMENT
For fitment follow reverse procedure of removal.
NOTE
Connector needs to be assembled before air bag
module fitment with CCB.
