ELECTRICAL
93
INSTRUMENT CLUSTER VARIANTS
SR.NO.
ENGINETYPE
1
1.05L CRAIL DIESEL
2
1.2 NA NG PETROL
TANK UNIT VARIANTS:
SR.NO.
ENGINETYPE
TANKUNIT
1
1.05L CRAIL DIESEL
35 Lit
2
1.2 NA NG PETROL
35 Lit
SPEED SENSOR VARIANTS:
SR.NO.
ENGINETYPE
SPEEDSENSOR
1
1.05L CRAIL DIESEL
08 Pulses / Rev. Non-
contact type
2
1.2 NA NG PETROL
08 Pulses / Rev. Non-
contact type
BASIC ELECTRICAL SPECIFICATIONS:
SR.NO.
PARAMETERS
SPECIFICATIONS
1
Nominal Voltage
13.5 V DC
2
Operating Voltage range
8 to 16 V DC
3
Test voltage
13.5 V DC
4
Boot-up time
< 0.5 secs.
5
Operating Current
2 Amps. Max. @ all loads ON
6
Sleep mode (Ignition off) current
< 1mA
7
Operating Temperature
- 30°C to + 85°C
8
Storage Temperature
-40°C to +85°C
