TIAGO

ELECTRICAL

TELL TALES

COLOR

INDICATOR

REMARKS

Airbag status

Red

Illuminates momentarily when ignition is switched ‘ON’

once engine is cranked, it goes OFF.

It will continuously illuminate when there is malfunction of

airbag (SRS) system. Contact TATA MOTORS Authorized

Service Centre urgently.

EPAS

Amber

Illuminates momentarily when ignition is switched ‘ON’

once engine is cranked, it goes OFF.

Illuminates when there is a fault in the EPAS. Contact

TATAMOTORS Authorized Service Centre urgently.

Low Coolant

Temperature

Blue

Indicates that engine coolant temperature is very low.

Illuminates

when engine coolant temperature is very low

and continuously

flashes along with buzzer if engine

coolant temperature is extremely low. Contact TATA

MOTORS Authorized Service Centre urgently.

High Coolant

Temperature

Red

Indicates that engine coolant temperature is very high.

Illuminates when engine coolant temperature is very high

and continuously flashes along with buzzer if engine

coolant temp. is extremely high. Switch off the engine and

allow cooling. Top-up coolant if coolant level is low. Contact

TATA MOTORS Authorized Service Centre urgently.

Low Fuel

Amber

Illuminates momentarily when ignition is switched ‘ON’

once engine is cranked, it goes OFF. Illuminates

continuously if fuel level is less than a pre-defined minimum

level. Refill the fuel tank as soon as possible. IMPORTANT:

The warning light flashes to indicate a fault in fuel system.

Contact TATA MOTORS Authorized Service Centre

urgently.

NOTE: Driving with low fuel level condition can cause the

engine to misfire and damage the catalytic converter (if

equipped).

Door Open

White

Illuminates when doors are open or when they are not

completely closed. If the driver’s side door is not closed

properly, a beep will sound for a few secs. When the

ignition is ON.

ABS

Amber

Illuminates momentarily when ignition is switched ‘ON’

once engine is cranked, it goes OFF. Illuminates

continuously if there is any malfunction in ABS. Normal

braking system will be operational without assistance of

ABS. Contact TATA MOTORS Authorized Service Centre

urgently.
