ELECTRICAL
97
TELL TALES
COLOR
INDICATOR
REMARKS
Diesel Pre-
Heat/Glow plug
indicator
Amber
Illuminates momentarily when ignition is switched ‘ON’ to
indicate that the glow plugs are active. It will continuously
illuminate when engine is getting preheated. Start the
engine only after the indicator goes off.
Turn Signal
Green
Indicates direction indicated by the turn signal. Blinks along
with buzzer while operating left/right turn indicator only
when ignition is switched ‘ON’.
High Beam
Blue
Illuminates when the high beam head bulbs are switched
ON or flashed.
Front Fog
Green
Illuminates when front fog bulbs are switched ‘ON’.
Low Oil
Pressure
Red
1. Illuminates momentarily when ignition is switched ‘ON’.
2. Illuminates continuously if engine oil level is less than a
pre-defined minimum level. Stop the vehicle as soon as
safety permits and switch off the engine. Check engine oil
level and top-up if required. Contact qualified TATA
MOTORS assistance before starting the engine.
Battery
charging/
engine warning
Red
Illuminates momentarily when ignition is switched ‘ON’
once
is cranked, it goes OFF.
It will continuously illuminate when there is malfunction of
charging system. Contact TATA MOTORS Authorized
Service Centre
Park Brake
cum
Low
Brake
Fluid/ABS or
EBD
Malfunction.
Red
1. Illuminates momentarily when ignition is switched ‘ON’
once
engine is cranked, it goes OFF.
2. When brake fluid level is low.
3. When park brake is applied and goes OFF when it is
released
4. When ABS/EBD system has a fault.
Seat belt
warning
Red
Indicates that seat belt is not fastened when ignition is ‘ON’.
It will flash along with buzzer for 6 secs when ignition is
switched ‘ON’ and seat belt is not fastened. It will continue
to flash until the car exceeds a speed of 20 kmph. After
that, it will remain continuously ON along with a buzzer that
will be audible for approx. for100 secs. Then buzzer goes
OFF but the indicator continues to remain ON until seat
belts are fastened.
