ELECTRICAL
49
8.10 POWER SOCKETS
One power sockets of 12V DC-10 amps each are
provided as shown in these can be used for
connecting loads up to 10A maximum. To use this
socket, remove the cap first.
REMOVAL AND REFITMENT
1. Pry out the socket holder assembly from
sideways.
2. Remove the electrical connection from power
socket.
REFITMENT
Install the power socket in the reverse order of
removal.
