ELECTRICAL
48
DIAGNOSTIC INFORMATION AND PROCEDURES
CONDITION
POSSIBLE CAUSE
CORRECTIVE ACTION/REFERENCE ITEM
Front wiper system not
working at all
Grounding point loose
Tighten the grounding properly
Front wiper motor Connector (
6
pole)
loose
Fix the connector properly
Front wiper motor faulty
Replace front wiper motor
Front wiper system does
not work in all speeds
Faulty Combi switch
Replace Combi switch
Front wiper not working
in intermittent delay
mode
intermittent wiper Relay loose
Fix the relay properly
No output from BCM
Refer BCM Diagnosis
Front Windscreen
washer not working
Water tank empty
Fill tank with Windscreen washer fluid
Washer tube joints are open
Connect the joints properly
Grounding point loose
Tighten the grounding properly
2 pole front washer pump
connector loose
Connect the connector properly
Front windscreen washer pump
faulty
Replace pump
Front windscreen washer switch
in combi-switch stalk faulty
Replace combi switch
Front Windscreen washer is controlled by BCM. If issue not resolved by above
methods, BCM diagnosis should be referred.
Both Washer and Wiper
Not working
Wash wiper fuse (
25 A
)
in cabin
fuse box loose/blown
Fix the fuse in the base properly. Replace if
blown
Rear wiper system not
working
Grounding point loose
Tighten the grounding properly
4 pole rear wiper motor
Connector loose
Fix the connector properly
Rear wiper motor faulty
Replace rear wiper motor
No output from BCM
Refer BCM Diagnosis
