ELECTRICAL
53
The specified resistance values of fuel level sensor w.r.t fuel tank level are given in below table:
Float Position
Full
3/4
Half
1/4
Empty High Empty Low
Resistance
value in Ohms
8
34
58
89
100
120
Tolerance in
Ohms
± 2
± 2
± 2
± 2
± 2
± 2
Height in mm
153.2
127.2
91.9
57.5
34.1
24.3
Volume (Liters)
(Usable)
34
28
19
11
5.5
3
