STEERING
24
3. Bulb fused
Replace bulb if blown
4. Battery supply not reaching
lamp LH/RH fuse input the
discontinuity in the circuit.
Check the continuity from p a r k i n g
battery to the lamps through the
combi-switch, Front W/Hand Floor
W/H connectors and rectify
Both parking lamps not
working at all
1. Combi switch connectors loose Fix the connectors properly
2. Combi switch faulty
Replace combi –switch
Registration plate lamp not
working
1. Bulb fused
Replace bulb
2. Grounding point loose
Tighten grounding properly
3. 2 pole lamp connector loose
Fix connector properly
Cabin lamp not working in
‘ON’ position
1. Bulb fused
Fix the bulb properly. Replace bulb if
blown
2. Switch erratic
Replace roof lamp
3. 3 pole Roof lamp switch
connector loose
Tighten the connector
CONNECTION DETAILS
For Circuit refer Circuit Schematic section.
