STEERING
22
High beam does not come
on when flash switch is
activated
1. Combi Switch connector loose Fix the connector properly
2. Flash switch faulty
Replace combi-switch
2 FRONT FOG LAMP (HIGH END) CONTROLLED BY BCM
CONDITION
POSSIBLE CAUSE
CORRECTION/REFERENCE ITEM
Single LAMP not working
1. Grounding point loose
Tighten grounding properly
2. Bulb fused
Replace bulb
3. No output from BCM
Refer BCM Diagnosis
Both lamps not working
1.Fog lamp fuse (10A) in cabin
F/R box blown
Check for short in the circuit and then
replace the fuse
2.Front fog lamp relay(20A) in
Engine F/R Box faulty
Replace relay
3. Front fog lamp switch faulty
Replace switch
4. No output from BCM
Refer BCM Diagnosis
5. Front fog lamp switch ground
point loose
Tighten grounding properly
6. Bulb loose/fused
Fix bulb properly. Replace if blown
3
INDICATOR LAMP WARNING LAMP AND OTHER LAMPS
CONDITION
POSSIBLE CAUSE
CORRECTION/REFERENCE ITEM
Front right / left signal lamps
not working
1. Grounding point loose
Tighten the grounding properly
2. 8 pole Head Lamp connector at
the lamp loose
Fix the connector properly
3. Bulb fused
Fix the bulb properly. Replace bulb if
blown
Rear right / left turn signal
lamps not working
1. Grounding point loose
Tighten grounding properly
2. 8 pole Rear Lamp Connector
loose
Fix the connector properly
3. Bulb fused
Fix the bulb properly. Replace bulb if
blown
Both Turn Indicators not
working
1. Flasher fuse (10A) in cabin
fuse box loose/blown(BASE &
MID)
Fix fuse properly in the base. Replace
fuse if blown
2. Flasher in cabin fuse box
faulty(BASE & MID)
Replace Flasher
